Electric Mountain Bikes Dual Suspension eMTB

Conquer the toughest trails and biggest laps with the Trek Rail+ 9.8 GEN 5 — a full-powered carbon e-MTB built for epic enduro, alpine lines and all-day back-country missions.

With 160 mm of front and rear travel, the latest Bosch Performance Line CX Gen 5 drive system, and an 800 Wh removable battery, it’s engineered to deliver performance, precision and serious fun.

Key Features & Benefits

• OCLV Mountain Carbon Frame
Internal routing, Motor Armour protection and Trek’s updated RIB 2.0 removable battery system for easier handling and service work.

• Mullet Wheel Setup
Sizes M–XL run 29″ front / 27.5″ rear for rollover and agility. Size S runs 27.5″/27.5″ for maximum control.

• 160 mm Front & Rear Travel
Paired with a premium Fox Performance Elite Float 38 fork and Fox Performance Elite Float X gives confidence in the roughest terrain.

• Bosch Performance Line CX Smart System
High-output power delivery, improved connectivity and the large-format 800 Wh PowerTube battery for maximum range.

• SRAM GX Eagle AXS T-Type Drivetrain
Wireless shifting, ultra-durable under load, low maintenance and perfect for steep Tasmanian climbs.

• Adjustable Geometry
Fine-tune your setup using the Mino Link flip-chip and optional angle-adjust headset cups — customise for your trails and riding style.

Who It’s For

Riders wanting a serious electric enduro machine that:
• Climbs efficiently all day
• Descends like a full-blown enduro bike
• Delivers long range + high torque
• Feels stable, planted and precise in real Tasmanian terrain

A premium, do-everything carbon e-MTB for riders who demand capability, reliability and fun on every lap.

The SAM² 6.8 is a full-suspension e-mountain bike built for fearless downhill and gravity-fed trail riding. With a robust 7005-series hydroformed aluminium frame, 165 mm F.O.L.D. suspension, coil shock tuned for downhill, and the powerful Bosch Performance Line CX motor, you’ll conquer rock gardens, jumps, and steep descents with total control. Ready for the biggest terrain and longest sessions.

Description

Experience the raw performance version of FOCUS’ SAM² platform — a bike designed for riders who demand serious downhill capability with the efficiency and range of a modern Bosch-powered e-MTB.

• Frame optimised for coil shocks and heavy-duty gravity riding.
• Mullet-wheel configuration (29″ front / 27.5″ rear) for roll-over stability and agile handling.
• Bosch Performance Line CX motor (85 Nm) with 600 Wh or optional 800 Wh battery upgrade.
• Fox 38 Rhythm fork (170 mm) and Fox DHX Performance coil shock (165 mm).
• Adjustable geometry — head-angle and chainstay length can be fine-tuned.
• Shimano Deore 4-piston brakes with 220 mm rotors.
• Approx. 26.5 kg (size M, 600 Wh version, without pedals).

Specifications

Frame: 7005 hydro-formed aluminium with 165 mm F.O.L.D. kinematics, 148×12 mm thru-axle, Post Mount 180 mm. Adjustable head-angle and chainstay length, integrated tool bag (except size S), hidden AirTag/Chipolo mount.

Suspension: Fox 38 Rhythm Grip 3-Position fork (170 mm travel) and Fox DHX Performance Coil shock (350/400/500/600 lbs springs for S/M/L/XL, 165 mm rear travel).

Drive Unit & Battery: Bosch Performance Line CX motor (85 Nm, upgradeable to 100 Nm via Flow App) with Bosch PowerTube 600 Wh battery (optional 800 Wh). Bosch Mini Remote + System Controller interface.

Drivetrain: Shimano Deore 12-speed shifter and derailleur with Shimano CS-M6100 cassette (10-51 T), Shimano CN-M6100 chain, Samox 165 mm cranks, and Samox 36 T chainring.

Cockpit: 800 mm alloy handlebar (30 mm rise), VP Lock-On grips, FOCUS C.I.S. 2.0 stem (40 mm), ACROS ZS56/ZS66 ICR headset with angle adjustment.

Seat & Post: FOCUS Comfort MTB saddle on Post Moderne DP-212 dropper post (125/170/200/200 mm travel by size, 34.9 mm diameter).

Brakes: Shimano Deore BR-M6120 4-piston hydraulic disc brakes with Shimano SM-RT66 220 mm rotors front and rear.

Wheels & Tyres: WTB ST i30 TGH alloy rims (29″ front / 27.5″ rear), Formula DC-611 front hub and DC-648 rear hub. Maxxis Assegai 29×2.5″ (DoubleDown 3C MaxxGrip) front tyre and Maxxis Minion DHR II 27.5×2.5″ (Downhill 3C MaxxGrip) rear tyre.

Weight: Approx. 26.5 kg (size M, 600 Wh battery, no pedals). System limit: 150 kg (rider + bike + gear).

Overview

The Focus JAM² 6.7 is an all-mountain e-MTB built for unlimited trail fun, up and down. With 160 mm front and 150 mm rear travel, Bosch Performance Line CX motor and the option of 600 Wh or 800 Wh batteries, it delivers playful handling on descents and plenty of support for big climbs. Balanced geometry, carefully tuned suspension and strong 4-piston brakes give you the confidence to ride harder, for longer.

Key Features

• Bosch Performance Line CX motor with 85 Nm torque and 100 Nm update via Bosch Flow App
• Choice of Bosch PowerTube 600 WH, plus compatibility with 250 Wh range extender (up to 1050 Wh total)
• 160 mm RockShox Psylo Silver RC fork and 150 mm RockShox Deluxe Select DebonAir+ rear shock
• SHIMANO CUES 10-speed drivetrain with LinkGlide cassette for long-lasting shifting performance
• Tektro Gemini SL 4-piston brakes with 203 mm rotors front and rear for powerful, consistent stopping
• 29" WTB ST i30 rims with Maxxis Minion DHF 29 x 2.5" tyres front and rear for grip and confidence on rough trails
• Integrated tool bag on larger sizes and a hidden AirTag/Chipolo mount so you always know where your bike is

Specifications

• Frame: 7005 hydroformed aluminium, 150 mm F.O.L.D. kinematics, 148 x 12 mm thru-axle, Post Mount 180 mm
• Fork: RockShox Psylo Silver RC, 160 mm travel
• Rear Shock: RockShox Deluxe Select, DebonAir+, 150 mm travel
• Motor: Bosch Performance Line CX, 85 Nm, Smart System (100 Nm update via Flow App)
• Battery: Bosch PowerTube Li-Ion 600 Wh or 800 Wh (removable)
• Display / Remote: Bosch Purion 200
• Drivetrain: SHIMANO CUES 10-speed – CUES shifter, CUES rear derailleur, Shimano CS-LG300 11–48T cassette, Shimano CN-LG500 chain
• Crankset / Chainring: Samox crank, 165 mm, with Samox 36T chainring
• Brakes: Tektro Gemini SL 4-piston front & rear
• Rotors: Tektro TR, 203 mm front & 203 mm rear
• Handlebar: Alloy, 800 mm width, 30 mm rise
• Stem: FOCUS C.I.S. 2.0, 40 mm
• Headset: ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. integrated
• Grips: VP Lock-On grips
• Saddle: Selle Italia X3 Boost
• Seatpost: Post Moderne DP-212 dropper, S / M / L / XL: 125 / 170 / 170 / 200 mm travel, 34.9 mm
• Rims: WTB ST i30, alloy, 29" front & rear
• Front Hub: Shimano HB-TC500
• Rear Hub: Shimano FH-TC500
• Tyres: Maxxis Minion DHF, TLE, EXO, 29 x 2.5" front & rear
• Weight: 25.6 kg (600 Wh) / 26.6 kg (800 Wh), size M, without pedals
• Permissible System Weight: 150 kg (bike, rider and gear combined)
• Special Features: Tool bag (excluding size S & M), hidden AirTag/Chipolo holder

Geometry Highlights

The JAM² 6.7 features modern, confidence-inspiring geometry with a 65° head angle, a 76.5° seat tube angle, and consistent 450 mm chainstays across all sizes. Combined with long reach numbers (425–510 mm from S to XL) and 29" wheels, it strikes a balance between playful handling and stability on steep, rough trails.

Fit & Sizing

Available in sizes S, M, L, and XL. For the best experience, we recommend a personalised setup to match your height, riding style, battery configuration 600 Wh, plus an optional 250 Wh range extender. Our team can help with frame size, cockpit setup, and suspension sag.

Why Ride Bellerive Recommends It

The Focus JAM² 6.7 is a seriously capable e-trail bike with a playful feel, big-day battery options and a smart, well-balanced build. It’s ideal for riders who want to climb efficiently, descend hard and make the most of Tasmanian trails with the support and reliability of Bosch’s latest e-MTB system.

Build & Workshop Support

Every Focus JAM² 6.7 from Ride Bellerive is fully assembled, safety-checked and professionally tuned by our workshop team. We’ll set up the suspension, controls and Bosch system so you can hit the trails with confidence from your very first ride.

The JAM² 6.8 is a high-performance all-mountain e-MTB built to climb efficiently and descend with confidence. Its 7005-series aluminium frame, 150 mm F.O.L.D. rear travel, and 160 mm RockShox suspension make it a powerful yet playful trail partner. Driven by the Bosch Performance Line CX motor and removable 600 Wh battery, it’s designed for big days on the mountain.

The FOCUS JAM² 6.8 delivers balanced geometry for all-day trail fun — equally at home on steep climbs or technical descents. With even weight distribution and precise handling, it’s one of the most versatile e-MTBs in the lineup.

Key features:

• 29″ wheel setup for superior traction and control

• Bosch Performance Line CX motor (85 Nm, upgradeable to 100 Nm)

• Bosch PowerTube 600 Wh battery (optional 800 Wh)

• RockShox Lyrik Select 160 mm fork and Super Deluxe Select 150 mm shock

• SRAM Eagle 12-speed drivetrain

• SRAM DB8 4-piston brakes with 200 mm rotors

• Adjustable geometry and hidden AirTag/Chipolo mount

• Approx 24.8 kg (size M, 600 Wh battery, without pedals)

Specifications

Frame: 7005 hydro-formed aluminium, 150 mm F.O.L.D. rear travel, 148×12 mm thru-axle
Fork: RockShox Lyrik Select, DebonAir+, 160 mm travel
Shock: RockShox Super Deluxe Select, DebonAir+, 150 mm travel
Drive Unit: Bosch Performance Line CX (85 Nm, upgradeable to 100 Nm)
Battery: Bosch PowerTube 600 Wh standard
Display: Bosch Mini Remote + System Controller
Drivetrain: SRAM Eagle 70 12-speed
Brakes: SRAM DB8 4-piston hydraulic disc with 200 mm rotors
Cockpit: Alloy handlebar (800 mm width, 30 mm rise), C.I.S 2.0 40 mm stem, VP Lock-On grips
Wheels: 29″ WTB ST i30 TGH alloy rims, Formula DC hubs
Tyres: Maxxis Dissector 29×2.4″ (front & rear)
Seatpost: Post Moderne DP-212 dropper post (125–200 mm travel by size)
Weight: Approx 24.8 kg (size M, 600 Wh battery)
System Limit: 150 kg (rider + bike + gear)

Why You’ll Love It

Whether you're rallying down steep chutes, pedalling into the wind on the climb, or carving your favourite trail, the Rail+ 5 Gen 5 is built to deliver. Here’s how:

• Attack the climb, dominate the descent. The Bosch system gives you the grunt you need to hit big climbs without dread — then the 160 mm suspension and aggressive geometry let you own the down.

• Adapt to your ride. Want a more playful feel or a more stable ride? Flip the chip, change the leverage rate, dial in your settings, and the bike changes character.

• Ride more, worry less. The 800 Wh battery gives you serious range, and with a removable battery design, you can charge at home, at work, or swap in a range extender for long days.

• Built rugged for real trails. The aluminium frame, internal routing, motor armour and quality components mean this bike isn’t just for show — it’s ready for serious off-road fun.

• Best value in high-end enduro e-MTBs. You get full travel, high-end suspension, Bosch smart system, and thoughtful geometry for a price point that punches above its weight.

Ideal For

• Riders looking for a full-power e-MTB capable of long all-mountain and enduro rides.

• Trail enthusiasts who demand both climbing efficiency and descending capability.

• Riders who want adjustability and geometry options to tailor their ride.

• Tassie riders who want a built-in range for epic Derby weekends without compromise (800 Wh battery + Bosch smart features).

---

The Fluid VLT A2 is an aluminium electric Trail bike designed and proven in the backwoods of British Columbia with a boost to ride faster and go further.

Shimano’s EP8 drive system combines high torque electric assist with your choice of 3 removable in-tube batteries.

720 WH Battery
